Max 3.7mm Diameter FUJI SMT NOZZLE NXT Second Generation H12 SMD Mounter Nozzles

  • 1
  • 2

Brand Name : FUJI

Model Number : NXT

Certification : CE

Place of Origin : Japan

MOQ : 1 PC

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000 pcs per month

Delivery Time : 1-3 work days

Packaging Details : Carton package

Product Name : FUJI NXT Nozzle

Shipping Term : TNT DHL FEDEX EMS UPS

Quality : Top

New : Original / copy

Mahchine : NXT pick and place machine

Nozzle Head : H12

Contact Now

Max 3.7mm Diameter FUJI SMT NOZZLE NXT Second Generation H12 SMD Mounter Nozzles

Introduce
The SMT nozzle is installed on the patch head and is used to pick up component patches and mount them on the circuit board. With the miniaturization and high density of components on circuit boards, higher requirements have been placed on the accuracy of placement machines, as well as higher requirements on the precision and quality of SMT nozzles.

SMT (Surface Mount Technology) nozzle is an important tool used in automated placement equipment for electronic components, used to pick up and place small electronic components. There are many types of SMT nozzles according to different needs, common ones include:

Round nozzle The round nozzle is the most common type, suitable for picking up and placing round electronic components, such as chip resistors, capacitors, etc.
Rectangular nozzle The rectangular nozzle is suitable for picking up and placing rectangular electronic components, such as IC chips, diodes, etc.
Needle nozzle Needle nozzle is suitable for picking up and placing elongated electronic components, such as inductors, crystal oscillators, etc.
V-shaped nozzle V-shaped nozzle is suitable for picking up and placing special-shaped electronic components, such as LED lamp beads, optocouplers, etc

Max 3.7mm Diameter FUJI SMT NOZZLE NXT Second Generation H12 SMD Mounter Nozzles

NXT H12/H08/H04/H01 Nozzle Series

Part Numbwr Description
AA05600 H0812 Yellow Φ0.45/0.3
AA05700 H08 Blue Φ0.7/0.5
AA05800 H08 Pink Φ1.0
AA20A00 H08 Green Φ1.3
AA06400 H08 Orange Φ1.3 Melf
AA20B00 H08 Aqua Φ1.8
AA19G00 H08 Orange Φ1.8 Melf
AA20C00 H08 Purple Φ2.5
AA06504 H08 Orange Φ2.5 Melf(R07-025M-070)
AA0WT00 H08 Purple Φ2.5G
AA20D00 H08 Yellow-Green Φ3.7
AA18C00 H08 Yellow-Green Φ3.7G
AA20E00 H08 Medium pruple Φ5.0
AA06300 H08 Red Φ5.0G
AA06W00 H04 Pink Φ1.0
AA06X00 H04 Green Φ1.3
AA06Y00 H04 Aqua Φ1.8
AA22Z14 H04 Orange Φ1.8 Melf
AA06Z00 H04 Pruple Φ2.5
AA07F00 H04 Pruple Φ2.5G
AA07A00 H04 Yellow-Green Φ3.7
AA07G00 H04 Yellow-Green Φ3.7G
AA07B00 H04 Medium pruple Φ5.0
AA07H00 H04 Red Φ5.0G
AA07C00 H04 Medium pruple Φ7.0
AA07K00 H04 Dark Red Φ7.0G
AA07D00 H04 Medium pruple Φ10.0
AA07L00 H04 Navy Φ10.0G
AA07E00 H04 Medium pruple Φ15.0(R19-150-155)
AA07M00 H04 White Φ15.0G(R19-150-155)
AA8WX00 H04S Φ2.5(R19-025-155-S)
AA8CC00 H04S Φ3.7(R19-037-155-S)
AA0AS00 H01 Pink Φ1.0
AA05800 H01 Green Φ1.3
AA0MZ00 H01 Orange Φ1.3 Melf
AA06900 H01 Aqua Φ1.8
AA11R00 H01 Orang Φ1.8 Melf
AA07000 H01 Purple Φ2.5
AA08400 H01 Purple Φ2.5G
AA07100 H01 Yellow-Green Φ3.7
AA08500 H01 Yellow-Green Φ3.7G
AA07900 H01 Medium pruple Φ5.0
AA07200 H01 Red Φ5.0G
AA08000 H01 Medium pruple Φ7.0
AA07300 H01 Dark Red Φ7.0G
AA08100 H01 Medium pruple Φ10.0
AA07400 H01 Navy Φ10.0G
AA08200 H01 Medium pruple Φ15
AA07500 H01 White Φ15.0G

We also have these brand nozzle on hot sale:
